Antique Appearance: Arc forming plus pitch stamping creates classic segmented glazed tile texture.
Stable Stamping: 400H frame with hardened shafts holds the profile during stamping.
Proven Drive: 5.5KW motor with double row chain transmission, 15 forming stations.
Precision Option: Servo motor drive available for accurate pitch positioning.
Ready Output: Hydraulic cutting with PLC control delivers length-accurate sheets.
Wide Use: Villa, temple, scenic and new Chinese style roofing and facade panels.
| Component | Specification |
|---|---|
| Profile | 5-peak antique glazed steel tile, arc + pitch stamping |
| Effective width | 740 mm |
| Feed width | 914 mm |
| Peak height | 28 mm |
| Pitch | 185 mm |
| Forming rows | 15 |
| Frame | 400H |
| Shafts | Φ75 mm, hardened |
| Main motor | 5.5 KW |
| Transmission | 6-division double row chain |
| Coil types | Color coated steel sheet |
| Optional | Servo motor drive, hydraulic cutting with PLC control |
One Pass Antique Tile: Arc forming and pitch stamping combined in one line.
Classic Texture: 5 peaks at 185mm pitch show clean traditional segment lines.
Stable Stamping: 400H frame and hardened shafts keep profile accuracy.
Proven Forming: 15 stations shape the 28mm peak height consistently.
Accurate Length: Hydraulic cutting with PLC control for ready to install sheets.
Precision Upgrade: Servo motor option for accurate pitch positioning.
Single Supplier: Machine, dies, cutting and service from one factory.
