Heavy Duty Manual Decoiler for Steel Coil Uncoiling

Heavy Duty Manual Decoiler for Steel Coil Uncoiling

Product Attributes :

Voltage 380V 50HZ three phase,customized

Power 5.5KW

Dimension(L*W*H) 1.5m × 1.2m × 1.0m

Weight (KG) 2500

Application Steel Coil Decoiler

Max.coil width 1500mm

Whatsapp +8615613727379

Product Description

Product Introduction:

High Load Capacity: Engineered to handle steel coils up to 5 tons, ensuring stable and reliable uncoiling for heavy-duty industrial applications.

Adjustable Tension Control: Features manual tension adjustment to maintain consistent coil feeding and prevent material deformation during uncoiling.

Durable Construction: Built with high-strength steel frame and precision bearings, designed to withstand continuous operation and harsh workshop environments.

Ergonomic Operation: Simple manual controls with safety locking mechanism, allowing operators to handle coils efficiently with minimal physical effort.

Wide Compatibility: Compatible with steel coils of various inner diameters (450-550mm) and outer diameters (1000-1250mm), suitable for diverse production needs.

Product Description & Parameters:
The Heavy Duty Manual Decoiler for Steel Coil Uncoiling is a reliable and cost-effective solution for industrial steel coil feeding. This equipment is designed to support and unwind steel coils manually, providing consistent tension control and smooth material feeding for downstream processing lines.

The primary advantage of this manual decoiler lies in its robust construction and operational simplicity. The high-strength steel frame ensures stability during heavy load uncoiling, while the precision bearing system minimizes friction and wear for long-term reliability. The adjustable tension control allows operators to optimize feeding speed and prevent coil deformation, ensuring consistent material quality. The ergonomic design with safety locking mechanism reduces operator fatigue and enhances workplace safety. This decoiler is the ideal choice for manufacturers seeking a durable, low-maintenance, and cost-effective uncoiling solution for their steel processing operations.

No.	Main Parameter / Feature	Details
1	Applicable Material	Steel Coil (Color Coated, Galvanized, Aluzinc)
2	Max Load Capacity	5 Tons
3	Coil Inner Diameter	450 - 550 mm
4	Coil Outer Diameter	1000 - 1250 mm
5	Max Coil Width	1250 mm (customizable)
6	Roller Diameter	70 mm
7	Tension Control	Manual Adjustable
8	Frame Material	High-Strength Steel
9	Bearing Type	Precision Industrial Bearings
10	Safety Feature	Locking Mechanism
11	Operation Mode	Manual
12	Surface Treatment	Corrosion-Resistant Coating
13	Installation	Floor-Mounted
14	Maintenance	Low Maintenance, Easy Access
15	Compatibility	Standard Steel Coil Sizes
16	Dimensions	Approx. 1.5m × 1.2m × 1.0m
17	Weight	Approx. 800 kg
18	Warranty	12 Months Free Warranty
19	Technical Support	Lifetime Technical Support
20	Customization	Coil Width and Diameter Customizable
21	Application	Steel Processing, Roofing, Cladding Production
