Machine type: Computer controlled double layer roll forming machine
Corrugated layer: 14 stations, 14 waves, covering 836 / 988
Trapezoidal layer: 14 stations, covering 900 / 1080
Feed widths: 1000 / 1200 / 1220 mm
Row match: 14 / 14
Two Profiles, One Frame: Trapezoidal and corrugated sheets from a single machine body.
Balanced Forming: Upper and lower sets each carry 14 stations, so neither profile is rushed.
Three Coil Widths: 1000mm, 1200mm and 1220mm feed widths are covered.
Computer Controlled: Length and batch settings are entered on the panel.
Steady Drive: A 5.5KW motor with a double row chain carries both layers.
Stable Frame: The 350H frame and 80mm shafts hold the section on long runs.
Space Saved: One line replaces two, which suits workshops with limited floor area.
| Component | Specification |
|---|---|
| Machine type | Computer controlled double layer roll forming machine |
| Corrugated layer | 14 stations, 14 waves, covering 836 / 988 |
| Trapezoidal layer | 14 stations, covering 900 / 1080 |
| Feed widths | 1000 / 1200 / 1220 mm |
| Row match | 14 / 14 |
| Frame | 350H |
| Shafts | 80 mm |
| Main motor | 5.5 KW |
| Chain drive | Double row chain |
| Control | Computer controlled, size and length setting from the panel |
| Middle plate | [To be confirmed] |
| Sheet thickness | [To be confirmed] |
| Cutting | [To be confirmed] |
| Line length | [To be confirmed] |
| Running speed | [To be confirmed] |
Two Products From One Line: Trapezoidal and corrugated sheets are both produced on the same frame.
Even Forming: Equal station counts keep the drive load and surface quality consistent.
Three Widths: One machine answers orders for three common coil widths.
Panel Control: Length, quantity and speed are set from the control panel.
Fewer Operators: One crew runs both profiles.
Low Waste: Coil widths are matched to the panel widths being produced.
Compact Footprint: The machine takes the floor space of one line, not two.
