Product Description
Product Overview
Our self-supporting floor deck profiles are high-strength steel building materials, professionally produced by self supporting floor deck roll forming machines through cold bending technology. Adopting high-grade galvanized steel raw material, it features great load-bearing capacity, anti-corrosion and stable structure, suitable for long-term use in steel structure construction.
Core Advantages
Adopting precise cold roll forming process, the floor deck has smooth surface, uniform thickness and accurate size. It integrates supporting and bearing function, easy cutting and installation, effectively shortening construction period and lowering overall project cost.
Application & Customization
Widely applied in high-rise buildings, industrial workshops, warehouses, commercial plazas and steel structure engineering. Various specifications and thickness of self-supporting floor deck can be customized to meet different structural load requirements.
Quality Assurance
All floor deck products and forming machines comply with international construction standards. Strict quality control ensures safe bearing performance. It is the preferred material and equipment for modern steel structure floor engineering, durable and cost-effective.
| Material Thickness | 0.8 – 1.5 mm |
| Yield Strength | 235 – 350 MPa |
| Effective Width | Customized according to deck profile |
| Deck Height | 38 mm / 51 mm / 60 mm / 76 mm (optional) |
| Roller Stations | 18 – 24 stations |
| Roller Material | Cr12, heat-treated |
| Shaft Diameter | 75 – 90 mm |
| Drive System | Gearbox or chain drive |
| Cutting Type | Hydraulic post-cutting |
| Control System | PLC with touch screen |
| Length Tolerance | ±1.0 mm |
| Power Supply | 380V / 50Hz / 3Phase(customizable) |
